Xlite 06 Red eTap AXS

Product code: 232685206

Time to shine.

Your colour Matt carbon

Your frame size

Your frame size

this is how you calculate your frame size

this is how you calculate your frame size

Back

THE FOLLOWING CALCULATION WILL HELP YOU FIND THE RIGHT BIKE FRAME SIZE AND SADDLE HEIGHT:

Road/Gravel Inside leg x 0,66 = Frame size in cm
MTB Size S: 155 – 172 cm body height
Size M: 173 – 182 cm body height
Size L: 183 – 192 cm body height
Size XL: >192 cm body height
Fitness
or
Inside leg x 0,61 = Frame size in cm
Inside leg x 0,24 = Frame size in inches
Hybrid/Touring
or
Inside leg x 0,61 = Frame size in cm
Inside leg x 0,24 = Frame size in inches
Inside leg x 0,885 = Saddle height on all bikes

If you are exactly between two sizes, you'll have the choice: Choose the smaller frame if you prefer a "racing position" and the bigger frame if you prefer a more comfortable "touring position".

See our video step-by-step instructions on how to determine your frame size. We'll explain you how to easily measure shoulder width, inside leg length and arm length yourself.
In case of any further questions regarding size calculation, please contact our experts!

Watch the corresponding video now!

5,799.00 € instead of €6,999.00

Best price in 30 days*: 5,799.00 € (0%)

Price incl. VAT plus €250.00 (for delivery to United States of America)

  • Built in Bocholt, Germany
  • Best quality for the best price
  • 6 Year Crash Replacement Service*** for frames and ROSE forks

The Xlite 06 Red eTap AXS loves adrenaline-packed hunts for speed. At 6.9 kg, this model is a nimble racing machine. Only flying is easier.

  • Weight
    ca. 6,9 kg¹
  • Frame material
    High Modulus Carbon
2326852-Antrieb_1
2326852-Antrieb_2
2326852-Antrieb_3

Fast, intuitive and reliable shifting performance

The 12-speed Red eTap AXS is SRAM’s absolute top-notch groupset. This groupset offers electronic wireless gears. The new gearing concept ensures nimble pedalling at any speed. The optimised rear derailleur ensures a consistently high chain tension. With an app, you can adjust the shifters to your needs.

2326852-Laufrad-Reifen_1
2326852-Laufrad-Reifen_2

Aerodynamic & agile

ROSE RC SIXTY carbon wheels make the XLITE even more aerodynamic and efficient. High-quality Newmen hubs and SAPIM bladed aero spokes give the wheel even better aerodynamics and outstanding stability. The 1620 g light, elegant carbon rim with 60 mm rim depth, 29.5 mm rim width and 3 mm offset is equipped with super-fast Schwalbe Pro ONE road tyres.

2326852-Lenker_1
2326852-Lenker_2
2326852-Lenker_3

Perfect design & full integration

The very stiff, light (approx. 395 g) and aerodynamic ROSE Race Carbon One-Piece cockpit perfectly integrates into the design concept of the XLITE. The design (83 mm reach, 130 mm drop, 3° flare) of the set-up allows for a modern, sporty riding position and style. What’s more, it offers more control in sprints or when riding out of the saddle to ensure a great performance.

Description

The most modern racing bike we have ever developed. Ride faster than ever before. Alone or in a group. In a sprint or on the mountain. Your time to shine is now!
The Xlite is an extremely well thought-out racing concept with an aggressive shape and progressive geometry. The riding position on the Xlite is uncompromisingly athletic, thanks to short head tubes and steep seat angles – every watt of your power is converted directly into speed.


¹ approx. 6.9 kg, may vary by up to +/- 5 % due to manufacturing tolerances, weight for matt carbon frame, size 57cm, without pedals

Features
Frame
ROSE XLITE 06 DISC, High Modulus carbon, PF86, 12x142TA, frame weight for 57 cm approx. 870 g Matt carbon 62cm
Handlebar stem combination
one piece cockpit Race, 120mm/42cm
Fork
Rose XLITE 04/06 DISC, carbon, 12x100TA, fork weight 370 g Matt carbon
Wheels
RC Sixty, carbon 24 hole
Wheels
RC Sixty, carbon 24 hole
Tyres
Schwalbe Pro One Evo, 28-622, schwarz/schwarz 622x28
Crankset
SRAM Red 48/35 DUB, 175mm
Cassette
SRAM XG 1290, 10-28
Front Mech
SRAM Red eTap AXS, Braze-on
Rear Mech
SRAM Red eTap AXS
Chain
SRAM Red, 12-speed,
116 links
Brakes
SRAM Red eTap AXS
Brakes
SRAM Red eTap AXS
Handlebar Tape
Giusti, Velvet black
Saddle
fi´zi:k Antares, black
Seat Post
ROSE d-shape, 14mm offset, 390mm, Ø27,2/390mm
Pedals
Pedals are not included and must be ordered separately
Frame geometry

Frame size

  • Frame size
  • a

    seat tube length (mm)

  • 430
  • 460
  • 480
  • 500
  • 525
  • 565
  • b

    Top tube length (mm)

  • 504
  • 523
  • 541
  • 558
  • 575
  • 593
  • c

    head tube length (mm)

  • 105
  • 120
  • 135
  • 152
  • 168
  • 192
  • d

    head tube angle (°)

  • 71
  • 72
  • 72,5
  • 73
  • 73,3
  • 73,5
  • e

    seat angle (°)

  • 75,5
  • 75
  • 74,5
  • 74
  • 74
  • 74
  • f

    BB drop (mm)

  • 72
  • 72
  • 72
  • 69
  • 69
  • 69
  • g

    chainstay length (mm)

  • 410
  • 410
  • 410
  • 410
  • 410
  • 410
  • h

    wheelbase (mm)

  • 975
  • 980
  • 990
  • 998
  • 1013
  • 1027
  • i4

    max. seat height (limited by seat post length 360mm) (mm)

  • 765
  • 795
  • 815
  • 835
  • 860
  • 900
  • j

    reach (mm)

  • 372
  • 382
  • 391
  • 398
  • 410
  • 422
  • j1

    Reach+ (mm)

  • 543
  • 553
  • 572
  • 589
  • 601
  • 623
  • k

    stack (mm)

  • 508
  • 527
  • 542
  • 557
  • 573
  • 597
  • k1

    Stack+ (mm)

  • 579
  • 598
  • 613
  • 628
  • 644
  • 668
  • m

    Standover height (100 mm in front of BB) (mm)

  • 730
  • 754
  • 781
  • 791
  • 812
  • 844
  • o

    stack to reach ratio (mm)

  • 1,37
  • 1,38
  • 1,39
  • 1,4
  • 1,4
  • 1,41
  • o1

    Stack to Reach ratio+ (mm)

  • 1,07
  • 1,08
  • 1,07
  • 1,07
  • 1,07
  • 1,07
  • p

    Fork offset (mm)

  • 45
  • 45
  • 45
  • 45
  • 45
  • 45
  • q

    Wheel diameter (inches)

  • 700C
  • 700C
  • 700C
  • 700C
  • 700C
  • 700C
  • r1

    Max. tyre width (mm)

  • 32
  • 32
  • 32
  • 32
  • 32
  • 32
  • u

    fork length (mm)

  • 372
  • 372
  • 372
  • 372
  • 372
  • 372
  • w1

    Handlebar Width (mm)

  • 400
  • 400
  • 420
  • 420
  • 420
  • 420
  • w2

    Crank Length (mm)

  • 170
  • 170
  • 172,5
  • 172,5
  • 175
  • 175
  • w3

    Stem lengh (mm)

  • 90
  • 90
  • 100
  • 110
  • 110
  • 120
  • x

    recommended size (cm)

  • 154-165
  • 164-172
  • 171-178
  • 177-186
  • 185-194
  • 193-200
  • z

    system weight (kg)

  • 110
  • 110
  • 110
  • 110
  • 110
  • 110
Reviews
(0)
(0)
(0)
(0)
(0)

Reviews in our webshop are checked for authenticity. To ensure that the reviews have been written by customers, only logged-in customers can write reviews. Reviews can only be submitted by logged-in customers who have purchased the product being reviewed, which is automatically checked against the customer's order history.

Discover all models

6_ICONs_Bild+Text-Modul_DESK

Category 6

This category applies to bicycles and e-bikes⁶ which meet the conditions of category 1 and which you ride in competitions (with great physical effort) or at other events at high speeds of more than 50 km/h, e.g. descents and sprints.

Average speed 30 to 55 km/h

Height of steps and drops: < 15 cm

Recommended rider skills: technical skills and practice required

⁶E-Bikes = 250W 25km/h
